Copyright © Sigicom AB 2021
Firmware upgrade is normally performed remotely via INFRA Net but
may also be done via the USB interface. See section 5.8.6.
Note! Use the plastic cap to protect the USB connector when not in
use.
2.6. Memory Card
The C22 uses a microSD memory card to store recorded data, system logs
and various status files to be communicated to INFRA Net. No
configuration data is saved on the memory card.
File formats on the memory card are only compatible with the INFRA
Net server and are not described in this manual.
The memory card can be accessible as a removable drive via the USB
connector, see section 5.8.5.
If the memory card is unintentionally missing (or corrupt), an error
message will be displayed at start-up.
Please contact Sigicom Support for guidance regarding memory card
formatting or other memory card issues.
Note! Only use a memory card approved by Sigicom.
2.7. SIM Cards
If activated when ordering, the embedded SIM card is used. This is pre-
configured for the customer.
If the customer needs to use their own SIM card, a mini-SIM card can be
inserted. The mini-SIM card must have an active “data plan”. The
inserted mini-SIM card will then be used instead of the embedded SIM
card.
