5.8.3. Clock Set
Time synchronization is handled automatically (see section 6.3), so
setting the clock manually is normally not needed.
For manual setting, select “Clock set” by pressing
→ Settings and actions → Clock set.
Note! To change the Clock settings, Monitoring must be OFF and
Communication mode set to Flight mode.
Use to step forward and arrow keys ( or ) to change a value.
Finish with the key.
Note! C22 will reboot after the clock is changed.
5.8.4. Clock Format
Time can be displayed in either 12- or 24-hour format, which is
configured by this selection. This configuration is only for the instrument,
INFRA Net is not affected by this.
