SIGLENT
116 SDG2000X User Manual
Users can program and control the instrument by using the SCPI commands
(Standard Commands for Programmable Instruments). For more information
about the commands and programming, please refer to “Remote Control
Manual”.
2. PC software
Users can use the PC software Measurement & Automation Explorer of NI
(National Instruments Corporation) to send commands to control the
instrument remotely.
Remote Control via USB
The SDG2000X can communicate with a PC through the USBTMC protocol.
You are suggested to do as the following steps.
1. Connect the device.
Connect the USB Device interface at the rear panel of SDG2000X with the PC
via a USB cable.
2. Install the USB driver.
NI Visa is recommended.
3. Communicate with a remote PC
Open Measurement & Automation Explorer of NI and choose the
corresponding resource name. Then click “Open VISA Test Panel” to turn on
the remote command control panel through which you can send commands
and read data.
Remote Control via GPIB
Each device connected to GPIB interface must have a unique address. The
