LCD OFF AND AUTO POWER OFF
The SD1 Merrill has [LCD Off] and [Auto Power Off] functions in order to
conserve battery power. If not used for a predetermined amount of time, the
color LCD monitor or power will be turned off automatically.
LCD Off
If not used for a predetermined amount of time, the backlight of the color LCD
monitor will be turned off automatically. Although the color LCD monitor is turned
off, the camera power remains ON, therefore, each button (except the
depth-of-filed preview button) can be operated normally. It is possible to change
to shooting mode, upon pressing the shutter button halfway.
Auto Power Off
If not used for a predetermined amount of time, the camera will be turned off
automatically. While the camera is in Auto Power Off, each button will not function.
It is necessary to press the shutter button halfway to terminate Auto Power off. It
is possible to change to shooting mode upon pressing the shutter button halfway.
Set the Auto Power Off from [
Camera Settings] (P. 2 8 ) → [LCD Off] and
[Auto Power Off].
LCD Off Option
A
uto Power Off Option
Of
f
Of
f
10 sec. 30 sec.
30 sec. 1min.
1 min. (Default) 5min. (Default)
5 min. 10 min.
10 min.
• icon is the recommended setting for conserving the electronic power.
TIP
• To disable LCD Off, set [LCD Off] to [Off].
• To disable Auto Power Off, set [Auto Power Off] to [Off].

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
