Sigma SD1 Merrill User Manual

59
3
Keep the shutter button depressed halfway while you compose the picture as
desired. Then press the shutter button the rest of the way to take picture.
z Focus Lock with the shutter button can be used with
(single AF mode) only.
The AF cannot be locked in
(continuous AF mode).
z Focus Lock can be done by pressing the AF button. After focusing, keep the AF
button fully depressed. (For more detailed information, please refer to P.6 0
“AF Drive and AF Button Setting”.)
z AF Focus Lock with the AF button can be used in
(continuous AF mode）as
well.
MANUAL FOCUS
In situations, where autofocus or focus lock is not effective, you can focus
manually.
1
Set the focus mode switch, on the lens to the
M position. (”MF” will be displayed in the
Function Display.)
2
While looking through the viewfinder, turn the
focusing ring on the lens until you get a clear
sharp image.
z When you use a lens, which has maximum aperture value of F6.3 or faster, the
focus indicator in the viewfinder will appear, when correct focus is attained.

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
