Sigma SD1 Merrill User Manual

92
*
3
In AF mode, the AF point which was used to achieve focusing will be illuminated
in red. If the picture was taken without focusing, the AF points will not be
illuminated in red.
In MF mode, if the picture was taken with a focus indicator lit, that AF point will be
illuminated in red. If the picture was taken while no focus indicators were lit, no
AF points will be illuminated in red.
While in Image Info Screen:
z Use A-dial ( ), to change the image selection the same way as in
Single-Image View.
z Use buttons to change the image selection the same way as in
Single-Image View. (See next section for the exception.)
z Press again to close the Image Info Screen and return to the previous
view.
z Press button to turn off the color LCD monitor.
MAGNIFIED IMAGES IN IMAGE INFO SCREEN
While the Image Info Screen is displayed,
it is possible to magnify the image by
rotating the S-dial ( ) to the
direction. It is possible to obtain detailed
histogram information for a particular
section of an image.
z For more information on the histogram see
the next section.
While magnifying the image in the Image Info Screen:
z Press the buttons to pan to another part of the image. (Histogram will
update automatically to reflect the new values.)
z Rotate the S-dial ( ) to the
position to increase magnification.
z Rotate the S-dial ( ) to the
position to decrease magnification.
z Press to cancel magnification and view the Image Info Screen for full
image. (Press
again to disable the color LCD monitor.)

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
