Sigma SD1 Merrill User Manual

57
AF POINT SELECTION
The SD1 Merrill is equipped with 11
focusing points. Selecting the AF point
can be done automatically or manually by
the photographer.
Press
button and select the desired AF
point by rotating the A-dial (
) displayed in
the viewfinder.
z The Selected AF point will be illuminated
in red in the viewfinder.
z Automatic AF point selection can be
achieved when all focusing points in the
viewfinder are illuminated in red.
z When you rotate the A-dial (
) clockwise, the selection will occur in the
looping sequence that follows.
AF points can be selected in the Function Display as well (P. 3 5 ). By pressing the
button, the Function Display will be displayed. Select the desired AF point
by using the
buttons.
z It is possible to move the AF area to up or down direction by using the
buttons and move to right or left direction by using the
buttons.
z If you press the same direction on the 4-way controller several times, it will
change to Automatic AF Selection mode. After that, if you press any button of
the 4-way controller, it will return to Manual AF Selection mode.
Automatic AF Selection mode
(All AF points will be illuminated.)

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
