Sigma SD1 Merrill User Manual

1
Thank you for purchasing
the Sigma Digital Autofocus Camera
The Sigma SD1 Merrill Digital SLR camera is a technical breakthrough! It is
powered by the Foveon® X3™ image sensor, the world’s first image sensor
to capture red, green and blue light at each and every pixel. A high-
resolution digital single-lens reflex camera, the SD1 Merrill delivers
superior-
quality
digital images by combining Sigma’s extensive interchangeable lens
line-up with the revolutionary Foveon X3 image sensor. You will get the
greatest performance and enjoyment from your new SD1 Merrill camera’s
features by reading this instruction manual carefully before operating it.
Enjoy your new Sigma camera!
• Please keep this instruction booklet handy for future reference. Doing so will
allow you to understand and take advantage of the camera’s unique features
at any time.
• The warranty of this product is one year from the date of purchase. Warranty
terms and warranty card are on a separate sheet, attached. Please refer to
these materials for details.
NOTES ON COPYRIGHT
This camera is intended only for personal use and should never be used in
a way that infringes upon or contravenes international or domestic copyright
laws and regulations. In addition, although it is intended purely for personal
use, some restrictions may be applied to photographing demonstrations,
performances, shows, exhibitions, or commercial properties, etc. Copyright
or other legal rights should not be contravened.
z CompactFlash is a trademark of SanDisk Corporation.
z IBM PC/AT series computer is a trademark or registered trademark of
International Business Machines Corporation (IBM) in the U.S.A.
z Microsoft and Windows are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
z Macintosh and MAC OS are registered trademarks or trademarks of Apple Inc.
in the U.S.A. and /or other countries.
z Adobe and Photoshop are trademarks of Adobe Systems Incorporated.
z All other company or product names used in documents are trademarks or
registered trademarks of their respective holders.
z Ricoh True Type Font designed by Ricoh CO., Ltd. is used for the display of
the menu window of this camera.

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
