Sigma SD1 Merrill User Manual

83
The SD1
Merrill is equipped with a PC Synchro Terminal, which accepts a
cable connection fro external/studio flash units.
CAUTION!!
• S-TTL auto flash does not work, if PC Synchro Terminal is used.
• Set the camera’s exposure mode to M and set to flash synchronized speed
Sync (1/180) or a shutter speed of 1/160 or lower. See the instruction manual
of the particular flash used for additional information.
• The SD1 Merrill’s PC Synchro Terminal is compatible with plugs that have a
positive (+) polarity on the central pin and a negative (-) polarity on the shield.
If the plug has reverse polarity, use a commercially-available polarity
conversion cord.
WARNING!!
• The PC terminal cannot accept flashes that use a voltage of more than 250V.
Higher voltage will damage the camera. Please ask the manufacturer of the
flash about the voltage and compatibility with the PC terminal.
AUTO ROTATE
It is possible to record the vertical image information to images.
Please set from [
Capture Settings] (P.2 8 ) → [Auto Rotate].
Off
The vertical image information will not be recorded.
On
(default)
The vertical image information will be recorded.
z When vertically orientated images are reviewed, they will automatically rotate
and be displayed vertically.
z When vertically orientated images are reviewed in Sigma Photo Pro, they will
automatically rotate and be displayed vertically.
z When vertically orientated images are rotated by pressing [
Playback
Menu] (P. 28 ) → [Rotate], the rotated orientation will be stored.

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
