Sigma SD1 Merrill User Manual

116
AC ADAPTER SAC-4
This is used to provide a constant electricity supply when shooting in the studio, or
taking indoor shots. It is also recommended for use when connecting the camera
to your computer to transfer data. (Please refer to page 23 for details)
MAINTENANCE
z Do not use chemicals or other cleaning agents such as thinners or benzene for
cleaning the camera and lens. Use a clean, soft cloth and blower to clean the
camera and lens. Lens cleaners can be used for removing fingerprints.
z Do not lubricate the camera, lens or lens contacts.
z Use a blower to remove dust and dirt from the color LCD monitor. To remove
fingerprints or other stains from the color LCD monitor, wipe the surface gently
with a soft, clean cloth. Do not apply excessive force, as this could damage the
color LCD monitor.
z The Sigma SD1 Merrill camera contains a dust protector located inside the
lens mount. The dust protector is a very delicate device and care must be
taken not to scratch its surface. Use a blower to remove dirt and dust from the
dust protector. Do not use a blower brush, as the bristles could scratch the dust
protector surface. To avoid damage, do not apply pressure to the dust
protector.
CLEANING THE IMAGE SENSOR
Although the SD1 Merrill is equipped with a dust protector to prevent dust or
dirt entering the camera, in rare circumstances, dust or dirt may adhere to
the image sensor, causing black spots to appear on images. If this occurs, it
may be necessary to clean the image sensor.
z The image sensor is extremely delicate and can easily be damaged. We
recommend that you contact an authorized Sigma Service Station to have the
sensor cleaned. We do not advise attempting the procedure yourself,
especially if you have no previous experience cleaning delicate optical
components.
WARNING!!
• The image sensor is a very important part of your camera. Please take all
necessary precautions to avoid damaging the sensor.
• Do not use an aerosol compressed air cleaner. Liquid may leak from the
cleaner and damage the image sensor or other electronics inside the camera.

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
