Sigma SD1 Merrill User Manual

126
Shutter Type
Vertical-travel metal focal plane shutter, electronically
controlled through entire speed range
Shutter Speeds
1/8000sec to 30sec, Bulb up to 30 (120) sec
*( ) Extended Mode
Flash Synchronization at 1/180sec.
Continuous Shooting
Up to approx. 5.0 fps (Image Size is set to HI)
Up to approx. 6.0 fps (
Image Size is set to MED or LOW )
Built-in Flash
S-TTL Auto Flash, Manual Pop-up Built-in flash,
GN11 (ISO100/m), 17mm lens angle covered
External Flash
Synchronization
Hot shoe
(contact X, with dedicated flash linking contact)
LCD Monitor Type
Aspect ratio3:2, 3.0" wide viewing angle TFT color LCD
monitor, approx. 460,000 pixels, Coverage area 100%
Reviewing Images
Single-Image display, Zoom-in display,
9 segments thumbnail display, Slide Sho
w
Language
English / Japanese / German / French / Spanish / Italian /
Chinese (Simplified) / Korean / Russian / Dutch / Polish /
Portuguese / Danish / Swedish / Norwegian / Finnish
Power Source
lithium ion battery BP-21
AC Adapter SAC-4 (Optional)
Dimensions 145.5mm/5.7"(W) X 113.5mm/4.4"(H) X 80.0mm/3.1"(D)
Weight 700 / 24.7oz (without battery)
CONNECTING YOUR CAMERA TO A COMPUTER
The SD1 Merrill camera can be connected directly to a computer using the
provided USB cable. Make sure that the camera is off before connecting it to the
computer. Data transfer rates will vary depending on the computer and operating
system used. For further information, please refer to Help within SIGMA Photo Pro.
CONNECTING THE CABLES
z Please confirm that [USB Mode] is set to
[Mass Storage] in the [
Camera Settings]
menu before connecting your camera to a PC
with supplied USB cable.
z The shutter button and the color LCD monitor
will be disabled while the camera is
connected to the computer via a USB cable.
WARNING!!
• Please use only the USB cable supplied with your camera.

Sigma SD1 Merrill Specifications

General

Megapixel	46 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	-
Total megapixels	48 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4704 x 3136 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Still image resolution(s)	4704 x 3136, 3264 x 2176, 2336 x 1568
Optical zoom	- x
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Normal focusing range (tele)	- m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	30 s
External flash connector	Yes
Maximum video resolution	- pixels
Memory slots	1
Compatible memory cards	CF
Flip-out screen	No
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.95 x
USB version	2.0
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Custom modes, Flash, Fluorescent, Incandescent, Shade, Sunny
Power source type	Battery
Product color	Black
Cables included	AV, USB
Bundled software	SIGMA Photo Pro

Weight and Dimensions

Depth	80 mm
Width	145.5 mm
Height	113.5 mm
Weight	700 g
