6.6 Switch-off delay for the flow setpoint of the switching transducer
EU3011V0000240 (230 VAC)
The desired value is set at the potentiometer “Delay” (Fig. 7). Turning the potentiometer
clockwise increases the time delay. The arrow indicates the set switch-off delay on the scale.
If the desired time delay has not yet elapsed during operation, the yellow LED lights up alt-
hough the red LED already indicates a flow drop.
Fig. 7: Switching transducer EU3011V0000240 (230 VAC)
6.7 Setpoint adjustment (temperature) of switching transducer
EU3011V0000240 (230 VAC)
The desired value for the temperature setpoint can be set using the "Temperature Setpoint"
potentiometer (Fig. 7). Turning the potentiometer clockwise increases the temperature set-
point. The arrow indicates the set temperature setpoint on the scale. When the set tempera-
ture setpoint is reached, the relay changeover contact switches.
