•Clamps
Left-hand carriage
The clamps (D) are rotating and four-sided to allow perfect closure of the key placed on its back or profile
in the case of keys with symmetrical cuts (chap.8.2, page 23).
Right-hand carriage
The clamps (J) are rotating, two/three sided to allow perfect closure of bit, double bit, pump and mail box
keys* (chap.8.3, page 27).
• Clamps knobs
The clamps are locked by two anatomical knobs (E) or (K), which ensure perfect grip on the keys with
only slight locking pressure.
•
Calibration tabs
The clamps have two gauge tabs (left-hand carriage) with which to adjust key alignment.
•
Brush
The brush (P) is used to eliminate burrs from the cuts and is made of non-abrasive material.
4.1 Technical Data
ELECTRICAL PROPERTIES:
- 230V-50Hz 300W 1,2A
- 120V-60Hz 250W 2,3A
CUTTING TOOLS: HSS Super Rapid Steel
MOTOR: One-speed single phase
- 230V-50Hz (1400 rpm)
- 120V-60Hz (1700 rpm)
MOVEMENTS: by gear on rectified carriage
CLAMPS: rotating 4 sides (left carriage), 2/3 sides (right carriage)
MAXIMUM LENGTH OF CUTS:
- flat cylinder keys: 42 mm
- bit and double bit keys: 25 mm
DIMENSIONS: width: 510 mm - depth: 450 mm - height: 280 mm
SONOROUS PRESSURE: Leq. = less than 70 dbA
WEIGHT: Kg.23
4.2 Graphics
* Mail box keys only on DUO and DUO BRAZIL versions
THE USE OF
PROTECTIVE GOGGLES
IS COMPULSORY
