Silca DUO POWER - Replacing Lamp

Operating manual - English DUO
Copyright Silca 2 010 41
9.11 Replacing lamp
ATTENTION: remove the mains plug.
1) Loosen the 4 screws (Q1) and remove the top cover (Q).
2) Loosen the light bulb (this may be facilitated by removing the shield (R1) or (R2).
3) Screw the new light bulb into the lamp.
4) Replace the top cover and secure with the 4 screws (Q1).
Fig. 61
T
T
Q1
Q1
R1
R2
