Silca DUO POWER - Page 21

Operating manual - English DUO
Copyright Silca 2 010 19
Fig. 21
Turn the nut to the RIGHT (clockwise) to take the tracer point down. Result: LESS DEEP CUTS.
Fig. 22
Turn the nut to the LEFT (anticlockwise) to take the tracer point up. Result: DEEPER CUTS.
cutting tool
N1
cutting tool
N1
