Sime GIULIA SYSTEM 25 User Manual

23
5.11.1 "Y" type
L N E
L N
CH ON
HW ON
HW OFF
R/S
ON
HW
ON
HW
OFF
C/S
ON
L N E
CH
ON
Caldaia
alla rete
TA 230V
1 L N E
R/S C/S
BL
Y-G
WH
G
OR
OP
FU
TA TBL
EVD
L Live
N Neutral
E Domestic hot water inlet
FU Fuse (3.15AT)
OP Mechanical timer
TA Room thermostat
TBL Hot water tank thermostat
EVD Diverter solenoid valve
BL Blue
G Green
OR Orange
YG Yellow/Green
WH White
Fig. 15
5.11.2 "S" type
L N E
L N
CH ON
HW ON
HW OFF
R/S
ON
HW
ON
HW
OFF
C/S
ON
L N E
CH
ON
Caldaia
alla rete
TA 230V
1 L N E
R/S C/S
OR
OR
G
BL
G
BL
Y-G
BR
Y-G
BR
OP
TA TBL
EV
EV
FU
L Live
N Neutral
E Domestic hot water inlet
FU Fuse (3.15AT)
OP Mechanical timer
TA Room thermostat
TBL Hot water tank thermostat
EV Solenoid valve
BL Blue
BR Brown
G Green
OR Orange
YG Yellow/Green
Fig. 16
