Discontinued products
Device Signalling Meaning reaction
WN.RN.XX
2X short (red LED) Power-on reset.
1x (signal LED)
Transmit/receive
power between two
WN.RN.R poor (test by
pressing button on
baseboard).
Improve the signal
quality (see
Improving
signal quality [}143] ).
2x (signal LED)
Transmit/receive
power between two
WN.RN.R sufficient
(test by pushing but-
ton on baseboard).
3x (signal LED)
Transmit/receive
power between two
WN.RN.R optimum
(test by pressing but-
ton on baseboard).
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WN.LN.C
2X short (red LED) Power-on reset.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
