Device Signalling Meaning reaction
WN.RN.R
Slow flashing (green
LED)
Ready to receive.
Fast flashing (green
LED)
Data transfer from/to
LockNode.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WN.RN.XC (Master)
WN.RN.CN.XC (Mas-
ter)
Flickering (red LED)
and green LED off.
No slave found in seg-
ment.
1. Check the cable
connection to the
slave.
2. Check the function-
ality of the slave.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WN.RN.CX (Slave)
WN.LN.C (Slave)
Flickering (red LED)
and green LED off.
No master found in
segment.
1. Check the cable
connection to the
master.
2. Check the function-
ality of the master.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WaveNet (Manual)
7. Signalling the operating status
