DL100 Series Universal Low-Power Inverter
4
Product Introdution
Output
signal
Relay and
OC output
One channel OC output and One channel relay output (TA, TC),
with up to 16 kinds of optional meanings.
Analog
output
One channel 0-10V voltage signal, and upper and lower limit can
be set.
Automatic voltage
regulation running
Three kinds of voltage regulation modes including dynamic, static
and none are available for selection according to different
requirements, so as to achieve most stable running effect.
Setting of acceleration
and deceleration time
0.1～600.0Sec continues setting.
Running function
Setting of upper and lower limiting frequency, REV running
limiting, RS485 communication, and control of progress increase
and decrease of frequency, etc.
Display
Display of
operation
panel
Running
status
Output frequency, output current, output voltage, motor
revolution, set frequency, module temperature, analog input and
output and
so on.
Alarm
content
The nearest 4 times of fault records, five items of running
parameter records at the time of latest fault trip including, the
output frequency, output current, output voltage, DC voltage and
modular temperature.
Protection/alarm function
Over current, overvoltage, under voltage, overheat, short circuit,
internal memory fault, etc
Environment
Surrounding
temperature
-10ºC to +45ºC (no freezing)
Surrounding
humidity
90% below (no frosting)
Surrounding
environment
Indoor (Free of direct sunlight, corrosion, flammable gas, oil mist
and dusts)
Altitude
0~1000m, the load is derated by 10% for each kilometer increase.
Protecting
grade
IP20
Cooling
mode
Forced air cooling
(Model 2S0004 is natural air cooling without fan)
Installation mode
wall-mounted
(Model 2S0004 must be mounted vertically on the wall)
Vibration
＜6m/s²
