DL100 Series Universal Low-Power Inverter
18 Operating Panel
4.3 List of status monitoring parameters
Monitoring code
Content
Unit
d-00
Inverter’s current output frequency
Hz
d-01
Inverter’s current output current (effective value)
A
d-02
Inverter’s current output voltage (effective value)
V
d-03
Motor revolution
rpm
d-04
Voltage at the DC terminal in the inverter
V
d-05
Inverter’s input AC voltage (effective value)
V
d-06
Module temperature
ºC
d-07
Set frequency
Hz
d-08
Analog input AI
V
d-09
Running liner speed
d-10
Set liner speed
d-11
Input terminal status
d-12
Analog output AO
V
d-13
Reserve
d-14
Reserve
d-15
Reserve
d-16
Reserve
d-17
Reserve
d-18
Reserve
d-19
Reserve
d-20
First fault record
d-21
Second fault record
d-22
Third fault record
d-23
Forth fault record
d-24
Output frequency at the time of recent fault
Hz
d-25
Output currency at the time of recent fault
A
d-26
Output voltage at the time of recent fault
V
d-27
DC voltage at the time of recent fault
V
d-28
Module temperature at the time of recent fault
ºC
d-29
Set frequency at the time of recent fault
Hz
d-30
Running status at the time of recent faul
d-31
Reserve
4.4 Simple operation of the inverter
4.4.1 Initial setting
(1) Channel selection for frequency input ([F0.00])
Inverter’s initial setting varies from each other according to different models.
When the parameter is set to 0, the inverters frequency setting will be set
through the panel digit.
(2) Selection of running command input channel ([F0.06])
The inverters initial setting varies according to different models. When this
parameter is set to [F0.06] =###0, the inverters start and stop control will be
