DL100 Series Universal Low-Power Inverter
Operating Panel 17
(2) Parameter inquiry and modification (example)
Normal status monitoring mode
Display :45.0 Output frequency
Parameter inquiry
Parameter inquiry
Parameter inquiry
Display:F0.00 Function code
Display:F0.01 Function code
Display:45.0 Parameter data
Display:50.0 Parameter data
Display:F0.01 Function code
Parameter save
Save modified
paramete
Parameter modification
Modify parameter
when necessar
Return
Abandon modification
Continue modifying other parameter or retum
Select
inquired/modified
parameteritem
