6.7 Communication setting parameter group
This parameter is used to set communication-related characteristics (decimal
setting).
LED units: baud rate selection
0：Reserve 1：1200bps 2：2400bps
3：4800bps 4：9600bps 5：19200bps
When using serial communication, you must ensure that both parties have the same
baud rate.
LED ten digits: data format selection
0：No verification 1： Even parity 2：Odd parity
When using serial communication, you must ensure that both parties have the same
data format.
Hundreds of LEDs: reserved
Thousands of LEDs: reserved
Set the local address of the inverter during communication, which is only valid
when the local machine is a slave. In the communication process, the machine only
sends back response frames to the data frames that match the address of the machine,
and receives commands.
0 is the broadcast address. For broadcast data, the slave executes instructions but
does not return corresponding data (see appendix communication protocol).
After the machine correctly receives the information code of the upper
computer, it is the waiting time before sending the response data frame.
When using the linkage function, the master is set to 0011 and the slave is set to
0000 to realize linkage communication.
F6.00 Communication settings Predetermined area
：
0000 ~ 0025
F6.01 Local address Predetermined area
：
0 ~ 127
F6.02 Local answer delay Predetermined area
：
0 ~ 1000 ms
F6.03 Linkage settings Predetermined area
：
0000 ~ 0011
