DL100 Series Universal Low-Power Inverter
Detailed Description of Functions 55
When the machine does not receive the correct data signal within the time
interval defined by this parameter. Then the machine judges that the
communication is malfunctioning. According to the working mode after
communication failure set in [F6.05], choose to stop or continue running.
LED units: action selection after communication failure
0： Downtime 1： Maintain current state
LED ten digits: reserved
Thousands of LEDs: reserved
This parameter defines the ratio of the output frequency of the master and the
slave during linkage control.
This group of parameters of the host inverter does not work. When the linkage
synchronization control is realized through the RS485 interface, the running
command of the slave machine is completely synchronized with the master
machine, and the frequency command of the slave machine is calculated as
follows:
Slave frequency command = Host frequency command × [F6.06]
This parameter is a check code value to obtain certain internal parameter query
and modification permissions.
Inverter control software version number, read-only parameter.
F6.05 Action setting after communication failure
Predetermined area
：
0000 ~ 0001
F6.06 Communication setting scale factor
Predetermined area
：
0.100 ~ 10.000
F6.08 Parameter query and modification permissions
Predetermined area
：
0 ~ 60000
F6.09 Program Version Predetermined area
：
1100 ~ 1199
F6.04 Communication timeout detection time
Predetermined area
：
0.1 ~ 20.0 Sec
