DL100 Series Universal Low-Power Inverter
Detailed Description of Functions 41
When [F0.00]=5, [F0.12]=9 or 10, and the external input terminal selects UP or
DW function, the frequency can be set through the external terminal. This
parameter is used to set the given frequency of the external terminal The rate of
rise and fall.
6.4 Digital input and analog parameter group
Used to select external digital input characteristics：
LED units： Define the characteristics of the X1 input channel
0：Positive characteristics 1：Inverse characteristics
LED ten digits:Define the characteristics of the X2 input channel
0：Positive characteristics 1：Inverse characteristics
Hundreds place of LED: Define the characteristics of X3 input channel
0：Positive characteristics 1：Inverse characteristics
LED Thousands: Define the characteristics of the X4 input channel
0：Positive characteristics 1：Inverse characteristics
The positive characteristic is valid when the terminal is closed and invalid when
it is disconnected; the inverse characteristic is valid when the terminal is
disconnected and invalid when the terminal is closed.
The function definitions of switch input terminals X1 ～ X4 are described as
follows:
0： without
1： Multi-speed control 1
2： Multi-speed control 2
3： Multi-speed control 3
The combination of the multi-speed control terminal is used to select the output
frequency of the multi-speed, and the specific frequency setting of each stage is
F2.16 UP/DW rate Predetermined area
：
0.10~10.00Hz
F3.00 Input channel characteristics selection
Predetermined area
：
0000~ 1111H
F3.01 Input terminal 1 function selection Predetermined area
：
0 ~ 21
F3.02 Input terminal 2 function selection Predetermined area
：
0 ~ 21
F3.03 Input terminal 3 function selection Predetermined area
：
0 ~ 21
F3.04 Input terminal 4 function selection Predetermined area
：
0 ~ 21
