DL100 Series Universal Low-Power Inverter
Product Introdution 3
1.4 Product technical indicators and specifications
I n p u t
Rated voltage,
frequency
Three phase (4T# series)
380V50/60Hz
Single phase (2S# series)
220V50/60Hz
Allowed variation
range of voltage
380 ~ 415V
±
10%
220V
±
10%
O u t p u t
Voltage
0 ~ input voltage
0 ~ input voltage
Frequency
0.00~600Hz
Overload capacity
110%--long term; 150%--1 minute; 180%--2 second
Control mode
V/F
C o n t r o l C h a r a c t e r i s t i c s
Frequency
set
resolution
Analog
terminal
input
0.1% of the maximum output frequency
Digital
setting
0.01Hz
Frequency
precision
Analog
input
Within 0.1% of the maximum output frequency
Digital
input
Within 0.1% of the set output frequency
V/F curve
(Voltage frequency
characteristics )
Reference frequency can be set within 5
～
600Hz, and multi-node
V/F curve can be randomly set.
Torque increase
Manual setting: 0.0～20.0% of rated output.
Automatic current
limiting and voltage
limiting
Automatically detect motor’s stator current and voltage and
control it within allowable range according to special algorithm,
regardless of any running process like acceleration, deceleration
or static running.
Under voltage limiting
during running
Especially for users of low-grid voltage and frequently fluctuating
grid voltage. Even within the voltage range lower than allowable
value, the system can maintain longest running time according to
special algorithm and residual capacity distribution strategy.
Ty p i c a l f u n c t i o n s
Multispeed cont0rol
7-section programmable multispeed control and 5 kinds of
running modes available for selection
Optional built-in PID
controller
Internal integrated optimized PID controller, allowing for simple
closed-loop control.
RS485 communication
and linkage control
MODBUS protocol.
Frequency
setting
Analog
input
DC voltage 0-10V, and DC current 0-20mA (optional)
Digital
input
Operating panel setting, potentiometer setting, RS485 port setting,
UP/DW terminal control, and multiple combined setting with
analog input.
