DL100 Series Universal Low-Power Inverter
14 Inverter Wiring
Analog
output
AO
Programmable voltage signal
output terminal (external voltage
meter set by [F3.16])
Voltage signal output
0-10V.
OCoutput
OC
Programmable open-circuit
collector output, set by
parameter [F4.00]
Maximum load current
50mA and maximum
withstanding voltage
24V.
Programm-
able output
TA/TC
Normally open contact capacity:
AC 250V, 1A resistive load ,
TA-TC function is set by
parameter [F4.01].
-
Communi-
cation
RS+/RS-
485 communication port
Convenient
communication
interface uses special
cable (optional) to
copy/download
parameters
conveniently through
485 communication.
