DL100 Series Universal Low-Power Inverter
Detailed Description of Functions 39
Boost voltage = × [F2.01]
The maximum output voltage is the corresponding output voltage when the
inverter outputs the basic operating frequency, generally the rated voltage of the
motor.
These two function parameters need to be set according to the motor parameters.
If there are no special circumstances, no modification is required.
Used to improve the low-frequency torque characteristics of the inverter. When
running in the low frequency range, the output voltage of the inverter is boosted
and compensated, as shown in Figure 6-8.
Figure 6-8 Schematic diagram of torque boost
F2.02 Torque boost Predetermined area
：
0.0 ~ 20.0
（
%
）
