Simplex 4100U User Manual

6-6
The system records the time at which each alarm, trouble, and supervisory event occurs. You can
view this information in one of two ways:
• By displaying or printing the historical alarm or trouble log. Refer to “Displaying Historical
Logs” later in this chapter for information on doing this.
• By scrolling through the list of active alarm, trouble, or supervisory conditions, selecting a
specific event, and using the EVENT TIME key. Refer to the procedure below for
information on doing this.
1. Select the alarm, trouble, or supervisory event whose event time you want to display. To do
this, follow these steps.
a. Press the FIRE ALARM ACK, PRIORITY 2 ACK, TROUBLE ACK, or
SUPERVISORY ACK key to enter the appropriate list of events. (For example, press the
FIRE ALARM ACK key to enter the list of active fire alarms.)
b. Use the NEXT and PREVIOUS keys to scroll through the list until the alarm in which
you are interested is displayed.
c. Press the EVENT TIME key. The time at which the alarm, priority 2 alarm, trouble, or
supervisory occurred appears in the display.
Viewing the Time at which an Event Occurred
Overview
Procedure
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
