Simplex 4100U User Manual

6-9
Historical logs provide a record of both the events that have occurred on the system and the
actions taken by an operator to manage those events. The system contains the following logs.
• Historical Alarm Log. Provides detailed information on each alarm, including time and date
stamp, that has occurred since the last time the logs were cleared.
• Historical Trouble Log. . Provides detailed information on each trouble, including time and
date stamp, that has occurred since the last time the logs were cleared.
1. Press the MENU key. Use the NEXT and PREVIOUS keys to scroll through the choices until
the “DISPLAY HISTORICAL ALARM LOG” or “DISPLAY HISTORICAL TROUBLE
LOG” choice is displayed.
2. Press ENTER to enter the log file.
3. Use the NEXT and PREVIOUS keys to scroll through the entries in the selected log.
Displaying and Clearing Historical Logs
Overview
Displaying/Clearing
Historical Logs
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
