8-10
1. Press the button labeled “Local Speaker Alert” to hear what is being played on the Alert
channel at that time. The LED associated with this button illuminates when the button is
pressed to indicate the function is active.
Note: If the user picks up the local phone or keys the microphone while the local speaker is
active, the speaker shuts off to prevent feedback. The local speaker turns back on when the
page is complete.
Press the Alarm Silence button on the front panel to silence the audio system. When you do this,
the speakers remain on, but play nothing.
Press the System Reset button to reset the audio system. When you do this, the following occurs.
All speakers and associated LEDs turn OFF.
The local speaker turns off.
Any paging that is in progress is canceled.
Two Channel Audio Operation, Continued
Listen to What is
Being Played on the
Alert Channel Using
the Local Speaker
Silencing the Audio
System
Resetting the Audio
System
