Simplex 4100U User Manual

5-3
1. Press the MENU key to enter the panel’s menu system.
2. Press the NEXT key until the alphanumeric display reads as follows:
3. Press ENTER. The display reads as follows:
4. Press the NEXT key to scroll through the categories of points until the appropriate category is
shown. Press the ENTER key. The first point in the selected category appears. In the
example below, the point shown is the first one in the monitor zone category.
5. Press the NEXT key to scroll through the list of points in the category. When the point that
you want to select is displayed, press ENTER.
Selecting Points from the Menu
Procedure
Press <NEXT> or <PREVIOUS> to scroll
Select a List of Points?
Press ENTER to select a list of points
All Monitor Zones?
MONITOR CARD 1 ZONE NUMBER 1
FIRE MONITOR ZONE NORMAL
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
