Simplex 4100U User Manual

5-2
When a point experiences an abnormal condition, such as an alarm, trouble, or supervisory, it is
added to the appropriate list (alarm list, supervisory list, or trouble list). Points within these lists
can be selected as follows:
1. Press the appropriate acknowledge key to enter the list. (For example, press the FIRE
ALARM ACK key to enter the list of current fire alarms; press the TROUBLE ACK key to
enter the list of current troubles).
2. Use the NEXT and PREV keys to scroll through the entries in this list. Stop scrolling when
the point you are interested in is displayed.
Selecting Points from Alarm, Trouble, Supervisory List
Procedure
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
