Simplex 4100U User Manual

7-2
The LAMP TEST key on the operator interface panel is used to determine local lamp failures
within the system. Lamps on the 4100 operator interface panel illuminate along with the five
function and acknowledge LEDs.
The tone-alert (buzzer) can also be tested with the LAMP TEST.
Do the following procedures to test for lamp failures.
1. Press the “LAMP TEST” push-button. All LEDs should illuminate (lamps should stay
illuminated as long as the key is depressed).
2. If you find defective lamps/LEDs, contact your local Simplex branch office.
Holding the Lamp Test key for more than 3 seconds tests the tone-alert.
Lamp Test / Tone Alert Test
Overview
Performing a Lamp
Test
Testing the Tone-
Alert
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
