Simplex 4100U User Manual

6-3
If the passcode entered in Step 5 is correct, the following message is shown.
After a brief pause, the system displays the granted access level, such as the level 2 message
shown below.
Press the <CLR> key twice. The display shows the system status, as shown below.
Failure to log out allows unauthorized personnel access to the various passcode protected
functions. If no keypad activity is detected for ten minutes, the system returns to Level 1 access.
Perform the following procedure to log out and return the operator access level to Level 1.
1. Press the <MENU> key. The following message is displayed.
2. Press the <ENTER> key. The following message is displayed.
Continued on next page
Logging In and Out of the System, Continued
Log In Procedure,
(continued)
Log Out Procedure
Enter a Passcode followed by <ENTER>
ACCESS GRANTED
1 = Login 2 = Logout
CURRENT ACCESS LEVEL = 2
1 = Login 2 = Logout
CURRENT ACCESS LEVEL = 2
Press <NEXT> or <PREVIOUS> to scroll
Change Access Level?
1 = Login 2 = Logout
CURRENT ACCESS LEVEL = 2
Technical Manuals Online! - http://www.tech-man.com
firealarmresources.com

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
