Simplicity 1693074 Service And Repair Manual

1 General Information
Specifications
1-12
14 HP Briggs & Stratton
Make: Briggs & Stratton - 4 cycle air cooled
Model & Type: See engine l.D. plate
Horsepower: 14 HP @ 3600 rpm (Eng. Mfg’s. Rating)
Cylinder: 1 horizontal
Bore & Stroke: 3.44 x 3.06 inches (87.3 x 77.7 mm)
Displacement: 28.4 cu. in. (465 cc)
Construction: Overhead valve, cast iron sleeves, aluminum
crankcase
Electrical: Vanguard - 12 volt 9 amp. alternator regulated
battery, 12 volt, 340 cranking amps, 41 minute
reserve capacity.
Diamond - unregulated 3 amp. DC charging
circuit.
Governor: Mechanical
Oil Capacity: 4.0 pints w/filter (1.9 L)
Ignition: Magnetron electronic
Charging: Diamond: Unregulated 3-amp DC,
Vanguard: Unregulated 9-amp DC
Air Cleaner: Ducted paper cartridge and foam pre-cleaner
Fuel Tank: High density polyurethane construction; 2 gal-
lons (7.57 liters) of “regular” grade leaded or
non-leaded gasoline.
Muffler Large, low back pressure, remote canister type
Starter: 12 volt electric gear drive
15.5 HP Briggs & Stratton
Make: Briggs & Stratton - 4 cycle air-cooled
Model & Type: Diamond I/C
Horsepower: 15.5 HP
Cylinder: 1 horizontal
Bore & Stroke: 3.44in.(87.3)mm
Displacement: 28.4cu.in.(465cc)
Construction: Overhead valve, Dura Bore Sleeves,
Aluminum Crankcase.
Electrical: 12 volt 9 amp, alternator
regulated battery, 12 volt, 340 cranking
amps, 41 minute reserve capacity.
Governor: Mechanical
Oil Capacity: 3 Pints w/Filter (1.4 L)
Ignition: Magnetron Electronic
Charging: Regulated 9 amp DC charging circuit
Air Cleaner: Tri-Clean
Fuel Tank: High Density polyurethane construction;
2 gallons (7.57 liters) of “regular” grade
leaded or non-leaded gasoline.
Muffler: Simplicity Custom Muffler
Starter: Electric
Specifications
ENGINE
16 HP Kohler Command
Make Kohler
Model Command CV16S
Horsepower 16 @ 3600 rpm
Cylinder 1 horizontal
Bore 3.55 in (90 mm)
Stroke 2.64 in (67 mm)
Displacement 26.0 Cu. in (426 cc)
Construction Overhead Valve, Cast-Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 15 amp. Alternator Regulated
Battery: 12 Volt, 340 Cold Cranking amps,
23 Min. Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam Pre-cleaner
Lubrication Full Pressure Lube w/Oil Filter
Oil Capacity 4.0 Pints w/Filter (1.9 L)
Fuel Tank Material: High-Density Polyethylene,
Transparent
Capacity: 2.0 Gallons (7.5 L)
Muffler Quiet Compact, Low Back Pressure
14 HP Kohler Command
Make Kohler
Model Command CV14S
Horsepower 14 @ 3600 rpm
Cylinder 1 horizontal
Bore 3.43 in (87 mm)
Stroke 2.64 in (67 mm)
Displacement 24.3 Cu. in (398 cc)
Construction Overhead Valve, Cast-Iron Sleeve,
Aluminum Crankcase
Electrical System 12 Volt, 15 amp. Alternator Regulated
Battery: 12 Volt, 340 Cold Cranking amps
23 Min. Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam Pre-cleaner
Lubrication Full Pressure Lube w/Oil Filter
Oil Capacity 4 Pints w/Filter (1.9 L)
Fuel Tank Material: High Density Polyethylene,
Transparent
Capacity: 2.0 Gallons (7.5 L)
Muffler Quiet Compact, Low Back Pressure
