Simplicity 1693074 Service And Repair Manual

1 General Information
Specifications
1-14
CONTROLS
Steering Full Circle Steering Wheel System, Gear and
Sector, 1.5 turns Lock to Lock.
Clutch/Brake Location Right Front
Pedal Combination Clutch/Brake Pedal
Parking Brake Foot / Hand Lock
Ground Speed Right side of seat deck
Shift Lever (Gear)
Ground Speed Right side foot rest
Foot Pedal (Hydro)
Throttle Control Combination Speed & Choke Control on left
side of dash board.
Key Switch Starter and Magneto ON/OFF Switch located
on Right side of seat deck
Mower Drive Electric Clutch PTO Switch located on right side
of seat deck
CHASSIS
Frame Heavy Gauge Steel Channel - 12/14 Gauge
Engine Mounting: Above Front Axle
Pivot Point Location: Rear Carrier
Rear Wheels Tire Size: 20 x 8-8 Turf Type or 18 x 8.50 -8
Inflation Pressure: 12-15 psi (82-103 kPa)
Front Wheels Tire Size: 15 x 6.00-6
Inflation Press.: 12-15 psi (82-103 kPa)
Bearings: Sintered Iron with Grease Fittings
Accessibility Hood Tips Forward for Engine,
Seat Tips Forward for Battery.
Seat High-Back, Quick Adjust, Spring Suspension
Turning Radius Inside Rear Tire: 14 in (36 cm)
Fuel Tank Material: Non-Corrosive Polyethylene
Capacity: 2 Gallons (7.5 L)
DIMENSIONS
Tractor
Overall Length 68 in (172 cm)
Overall Width 36 in (92 cm)
Height At Steering Wheel: 41 in (104 cm)
To Top of Engine Cover: 34 in (86 cm)
Wheel Base 50 in (127 cm)
Weight (Apx. Net) 371 lbs. (168 kg)
w/44 in mower 463 lbs. (210 kg)
Tractor Height
w/Snowcab est. 70 in (177 cm)
Tractor Length
w/Snowthrower est. 90 in (228 cm)
Tractor Length
w/Dozer Blade est. 86 in (218 cm)
44” Mower
Thickness 12 Ga.
Effective Cutting
Width 44 in Mower - 44 in (111.8 cm)
Overall Width
with Deflector 56 in (142.2 cm)
with Turbo 44 in Mower - 58in (147 cm)
Weight 107 lbs. (49 kg)
Cutting Height Variable: 1.5 to 3.9 in (3.8 to 10 cm)
Blade Arrangement Three Staggered Blades
Mower Drive V-Belt from Tractor PTO Electric Clutch
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
38” Mower
Thickness Early Models: 14 Ga., Later Models: 12-Ga.
Effective Cutting
Width 38 in Mower - 38 in (97 cm)
Overall Width
with Deflector 49.5 in (126 cm)
with Turbo 38 in Mower - 51.5 in (131 cm)
Weight 81 lbs. (36.7 kg)
Cutting Height Variable Between 1.5 and 3.9 in (3.8 and 10 cm)
Blade Arrangement Two Staggered Blades
Mower Drive V-Belt from Tractor Engine PTO Electric Clutch
Spindle Bearings Sealed Ball Bearings - Lube Fitting Provided
