16 - 3
16 Mower Deck Service
38” Mower Deck - Housing, Arbors, & Blades
Ref. Qty. Description
1 2 NUT, Hex, Flange, 9/16-8
2 4 WASHER, Belleville
3 1 PULLEY, LH
4 1 LOCKNUT, 5/16-18
5 2 HUB
6 2 COVER, Arbor Housing
7 4 BEARING
8 2 SPACER
9 2 GASKET, Foam
10 2 ARBOR HOUSING ASSY. (Incl. Fitting Ref. 11)
11 2 FITTING, Grease
12 1 BELT STOP, LH
13 4 NUT, Hex, 5/16-18
14 4 LOCKWASHER, 5/16
15 4 WASHER, Flat, 3/8
16 1 SCREW, Taptite, 5/16-18 x 1-1/2
17 2 WASHER
18 2 SHAFT, Arbor
19 2 SHIELD, Grass, Lower
20 1 BLADE, Mower, 16-1/8”
21 1 BLADE, Mower, 22-1/4”
22 2 WASHER, Hex
23 2 WASHER, Spring
24 2 CAPSCREW, Hex, Hd., 7/16-14 x 1
25 7 SCREW, Taptite, 5/16-18 x 3/4
26 1 MOWER DECK HOUSING, 38,” Orange
26 1 MOWER DECK HOUSING, 38,” Black
27 2 CARRIAGE BOLT, 1/4-20 x 7/8
28 1 DEFLECTOR, Plastic
29 2 NUT, Push
30 2 WASHER, Plain
31 1 CLAMP
32 1 WASHER, Plain, 5/16
33 1 SPRING
34 2 LOCKWASHER, 1/4
35 2 NUT, Hex, 1/4-20, Unc
36 1 ROD, Deflector, Front
37 1 PULLEY, RH
38 1 BELT STOP, RH
39 4 SCREW, Taptite, 5/16-18 x 1
40 2 PLUG, Plastic
38” Mower Deck - Housing, Arbors, & Blades
