6 General Repair
6C Foot Controls Repair
6 - 44
Figure C–24. Broadmoor Hydro Foot Control - Actuator Assembly Parts - Eaton 750 / 751 & Tuff Torq K60
A. Cotter Pin
B. 11/32 Washer
C. Actuator Assembly
D. Clutch Lever
E. Idler Pivot Assembly
F. Drive Spring
G. Spacer
H. 13/32 Washer
I. Idler Pulley
J. 3/8-16 Flange Whizlock Nut
K. V-Pulley
L. 5/8 Clip ring
M. 5/8 Washer
N. Spacer
O. 3/8-16 x 1-3/4 Hex Capscrew
NOTES:
1. Unless specified, use torque specifications shown on standard hardware torque specification chart.
2. Grease locations indicated by grease gun symbol:
3. Oil locations indicated by oil can symbol:
A
B
C
D
B
A
F
G
H
I
H
J
M
E
L
J
H
K
G
H
N
O
O
Early Models Only
Early
Models
Only
Clutch Rod
To Foot
Pedal
Arm
Brake Rod
To Transmission
To Transmission
Return-to-
neutral Rod
To Slot In
Transmission
Bracket
To Next Page
