Simplicity LTH Series

7 - 57
7 Transmission Repair
7C Tuff Torq K60
30. Remove the fulcrum pin from the transaxle case.
Figure C–41. Remove Fulcrum Pin From Case.
31. Remove the cotter key from the bypass shaft.
32.Remove the bypass shaft and spring from the
transaxle case.
Figure C–42. Remove Bypass Shaft
33. Remove the small retaining ring from the input shaft
(above case seal).
34. Remove the input shaft seal using care not to dam-
age the transaxle case.
36. Remove the large retaining ring (under seal) holding
the shaft bearing in place.
Figure C–43. Remove Retaining RIngs and Seal
