22 |
Installation | V5035 Operator and Installation Manual
Connector Label name Description Function usage
Pilot plug
PILOT_IN GND Input Ground Pilot plug port
PILOT_IN A Input A
PILOT_IN B Input B
PILOT_OUT GND Output Ground
PILOT_OUT A Output A
PILOT_OUT B Output B
Alarm
ALARM NO Alarm normally open
ALARM NC Alarm normally closed
ALARM COM Alarm common
DGPS
input
DGPS_IN GND DGPS input ground DGPS sensor
DGPS_IN A DGPS input A
DGPS_IN B DGPS input B
DGPS
output
DGPS_OUT GND DGPS output ground DGPS sensor
DGPS_ OUT A DGPS output A
DGPS_ OUT B DGPS output B
LR input
LR_IN GND LR input ground Long range input
LR_IN A LR input A
LR_IN B LR input B
LR output
LR_OUT GND LR output ground Long range output
LR_ OUT A LR output A
LR_ OUT B LR output B
Display
DISP_IN GND DISP input ground Connect to the data output
of an external display system
such as ECDIS.
DISP_IN A DISP input A
DISP_IN B DISP input B
DISP_OUT GND DISP output ground Connect to the data input of
an external display system
such as ECDIS.
DISP_OUT A DISP output A
DISP_OUT B DISP output B
Blue sign
BLUE_SIGN A Connect to a blue sign switch.
BLUE_SIGN B
¼ Note: RTCM-SC-104 beacon input is currently not implemented by
the DGPS_IN input.
