Simrad V5035 User Manual

74 |
Technical specications | V5035 Operator and Installation Manual
DGNSS correction input RTCM-SC-104
Alarm relay Normally closed
USB Mini type B USB interface
NMEA2000 IEC61162-3
Alarm Output Relay contact
Environmental
Operating Conditions IEC 60945 “protected” category
Operating Temperature -15°C ~ 55°C
Operating Humidity 95% RH at 40°C
Waterproof IPX2
Physical
Width 205 mm (8.07 inch)
Height 85 mm (3.34 inch)
Depth (include connectors) 160 mm (6.30 inch)
Weight ≦ 1.16 kg
Pilot plug
Cable length 2 m
Connector type Std. Sex 206486-2
NMEA 2000 PGN information
The following table is a list of the NMEA 2000 messages supported
by the V5035 unit.
The “Transmit” PGNs information includes “Own ship” + “Received AIS
information from other ships”. This is the reason the NMEA2000 PGN
list covers both Class A and Class B related information.
Transmit
PGN Description
59392 ISO Acknowledgment
59904 ISO Request
60928 ISO Address Claim
