| 63
Operation | V5035 Operator and Installation Manual
and 5V. It also enables to switch the transmission power between
12.5W, as “normal”, and 1W.
TRANSCEIVER SETTING
2013/01/17 22:43:39
Targets Received: 10
DSC RX <ON>
AIS TX <ON>
GPS ANT. VOLTAGE <3.3V>
GPS MODE <At sea level>
TX POWER <Normal>
For inland vessels that operate at altitude higher than 500 meters,
the transponder needs GPS Mode set to “Altitude higher than 500m”
for better GPS positioning performance.
To save the settings, press MENU or ESC and the system will ask
whether the changes should be saved. Select OK to save or CANCEL
to discard and return to main menu.
Sys Cong
System configuration provides access to user configurable prefer-
ences for V5035. All user settings are stored within the transponder
and will be maintained if the power supply is switched off.
After the setting is done, press MENU or ESC and the system will ask
whether the changes should be saved. Select OK to save or CANCEL
to discard and return to main menu.
MENU
Dangerous Targets :0
PASSWORD
LONG RANGE SET.
LR BCST SET.
DEST. TABLE SET.
ALARMS SETTING
VSWR SETTING
SYS CONFIG
MENU
Dangerous Targets :0
MAIN MENU
MESSAGES
NAV. STATUS
SHIP SETTING
TRANSCEIVER
SYS CONFIG
DIAGNOSTICS
SYS CONFIG
CUSTOMIZE
RADAR VIEW
MAP CALIBRATION
SENSOR CONFIG.
FACTORY
PASSWORD
MAIN MENU
MESSAGES
NAV. STATUS
SHIP SETTING
TRANSCEIVER
SYS CONFIG
DIAGNOSTICS
System conguration
Customize
Customize provides personalization settings:
• Dimmer Level - brightness setting from 1 (low) to 100 (high)
• Colour mode - brightness and contrast adjustment for the LCD
display along with selection of day or night operating mode. In
