Technical specications | V5035 Operator and Installation Manual
Technical specications
Applicable standards
IMO Resolution A694(17) IEC 61993-2 Ed. 2.0, 2012
IMO Resolution MSC.74(69)
Annex 3
IEC 61108-1 Ed. 2.0, 2003
IMO Resolution MSC. 191(79) IEC 60945 Ed. 4.0, 2002 incl. Corr.
1 2008
ITU-R M 1371-4 (Class A), 2010 IEC 61162-1 Ed. 4.0, 2010
ITU-R M 825-3, 1998 IEC 61162-2 Ed. 1.0, 1998
ITU-R M 1084-5, 2012 IEC 62288 Ed. 2.0, 2014
VHF transceiver
Frequency Range 156.025 MHz ~ 162.025 MHz
Channel Bandwidth 25 KHz
Modulation GMSK / FM
Data Rate 9,600 bps
Number of AIS Transmitter 1
Number of AIS Receiver 2
Number of DSC Receiver 1
AIS Channel 1 CH 87B (161.975 MHz)
AIS Channel 2 CH 88B (162.025 MHz)
Tx Power Output 1/12.5 Watt (30/41 dBm ± 1.5 dB)
Rx Sensitivity < -107 dBm @ 20% PER
DSC receiver
Frequency 156.525 MHz
Modulation FSK
Channel Bandwidth 25 KHz
Sensitivity < -107 dBm @ BER < 10-2
Spurious Response Rejection ≧ 70 dB for signal @ -104 dBm;
BER ≦ 1 %
Blocking ≧ 84 dB for signal @ -104 dBm;
BER ≦ 1 %
5
