Operation | V5035 Operator and Installation Manual
Diagnostics
This submenu provides users to check system statuses. There are a
total of 8 check options.
SYSTEM ON/OFF
MEMORY TEST
SENSOR PORT
TFT-PANEL
KEYBOARD TEST
GPS STATUS
NAV. STATUS
SHIP SETTING
TRANSCEIVER
SYS CONFIG
System On/O: This option provides activation history (any power-
off session less than 15 minutes would not be registered in the
history).
Memory Test: This option provides memory testing on the unit.
Sensor Port: This option provides an overview of baud rates on all
ports and status information.
TFT-Panel: This option provides color information on the monitor.
Keyboard Test: This option provides keyboard testing. Pressing
button during testing, a corresponding button on the screen will
response. After all buttons are tested, a message will indicate. Press
knob for OK to exit. To quit test without completing, wait for 30
seconds and the system will return to the main menu.
KEYBOARD TEST
2013/01/17 22:43:39
Dangerous Targets: 2
MENU
LEFT RIGHT
ESC
USER
DIMMER
ENTER
SRM
DISPLAY
KEYBOARD TEST
Dangerous Targets: 2
MENU
LEFT RIGHT
ESC
USER
DIMMER
ENTER
SRM
DISPLAY
Check Pass
OK
Keyboard test
GPS Status: This option provides GPS satellite status information.
Green indicates satellite being used for GPS fix. Red indicates satel-
lite not being used.
