Operation | V5035 Operator and Installation Manual
Operation
Panel description
1 2 3
Item No. Name Description
1 Power switch Power On/Off (push button over 5
seconds)
2 Beeper Sounds when buttons are pushed and
by MOB alarm
3 Display 3.5” LCD color screen
Key Description
MENU Return to main menu / detail menu select
FUNC Different function on display mode (Zoom In/Out,
etc) and has different roles in submenus
DIM Adjust dim degree (refer to page 34)
Knob Rotate to select, press to confirm
DISP Change to different display modes:
1. Coastal view
2. Radar view
3. AIS target list
4. Dangerous target list
5. Own ship detail
6. GPS satellite information
7. Region setting list
SRM Emergency SRM broadcast
ESC Cancel/Back to main menu, or press and hold for 3
seconds to access alarm list
4
