Operation | V5035 Operator and Installation Manual
Status bar
The status bar constantly indicates Date (YYYY/MM/DD), Time, GPS
status, ALR, and SRM.
1°13’02”N
103°48’32”E
12.00Kn
360.0
°
2013/01/01 07:18:11
Targets Received: 3
SIMRAD: 15
RNG
BRG
SOG
COG
HDG
SIMRAD: 15
N
12.000NM
Own Ship
Own Ship
12.00Kn
N/A
0.0
°
Status Bar
Status bar
Icon Description
GPS Status: position fixed
GPS Status: non-fixed
ALR Status: alarm messages occurs
Inbox SRM: unread coming SRM message
SART/MOB: SART or MOB message received
EMMA warning (RFM23): warning received
ETA/RTA: message received
Water levels (RFM24): message received
Transmission and reception bar
The Transmission & Reception bar constantly displays real time
status of transmissions and receptions on any display modes. The
3 default displayed messages are received AIS targets, dangerous
targets, and Tx power level.
