| 71
Operation | V5035 Operator and Installation Manual
and eligible for communication testing. The left screen below indi-
cates no valid Class A targets found.
COMMUNICATION TEST
2013/01/17 22:44:22
Targets Received: 10
--- DEST. MMSI ---------- DATE/TIME --- RX ACK
NO VALID CLASS A TARGETS
OK
COMM. TEST TARGET
COMMUNICATION TEST
Targets Received: 10
PRESS ROTARY SWITCH TO SELECT
DESTINATION MMSI OF MESSAGE 10
DEST. MMSI <566884302 (19.84NM>
Send Message?
OK CANCEL
No valid targets
After pressing the knob, turn the knob to selected destination MMSI
for testing. The destination MMSI numbers are the nearest Class A
targets found close to the Class A unit. Press ESC or MENU to pick
selection and the unit will prompt to confirm message sending.
Select OK to proceed testing.
Panel Test
In the submenu users can test the brightness of the screen.
Press “FUNC” to switch the white cube between different sizes. Ro-
tate the scroll wheel quickly to test different stages of brightness. To
exit the function, press “MENU” or “ESC”.
Test with size and brightness
Version
Provide model name, hardware information, delivered firmware ver-
sion on the unit, etc. When finished, press ESC to exit.
VERSION
Targets Received: 10
FIRMWARE V1.0.6.39
PRODUCT V5035 - AIS Class A
COMPANY Alltek Marine
WEBSITE
hp://www.alltekmarine.com
S/N A4K7000001
V5035 - AIS Class A
V1.0.6.41
Simrad
pro.simrad-yachting.com
A4K7000001
Version information
