Simrad V5035 User Manual

| 49
Operation | V5035 Operator and Installation Manual
Static data and dynamic data
OWN SHIP <1/2>
2013/01/17 22:43:39
Dangerous Targets :0
NAME SIMRAD
CALL CS09
MMSI 211111111 [CLASS A]
NAV. Under way using engine
LON 121°45’00”E
LAT 025°09’25”N
SOG 12.00Kn
COG 298.0°
ROT N/A
000/023
EPFS GPS
RNG Own Ship
BRG Own Ship
CPA 5 NM (set)
HDG N/A
TCPA 10 min (set)
P.A. Hi
Manoeuvre Ind. not available
RAIM In use
TX POWER 12.5 W
OWN SHIP <2/2>
2013/01/17 22:43:39
Dangerous Targets :0
CALL 0001
MMSI 211111111
CARGO N/A or Harmless
TYPE Vessel-Pleasure cra
NAME SIMRAD
DEST TPE_259
ETA 02/25 01:02
BEAM 87m
Pos. Quality Posion with
RAIM <=10 m
000/023
DRAUGHT 1.0m
IMO 111111111
DTE AVAILABLE
[CLASS A]
A:40m B:41m C: 42m D:45m
A
B
C
D
LENGTH 81m
Static data and dynamic data
Inland vessel information
This option displays the full information on your ship, including both
dynamic and static data.
Turn the knob to change between dynamic and static information.
OWN SHIP <3/4>
2013/01/17 22:43:39
Dan
g
erous Tar
g
ets :0
ENI
Ship Len. (RFM 10)
Ship Beam (RFM 10)
Type Of Ship
[8021-Motor tanker, liquid cargo,]
Blue cones
Draught (RFM 10)
Load Status
Quality Of Speed
Quality Of Course
Quality Of Heading
IL
[A1234567]
[180.1m]
[150.2m]
[B-Flag]
[15.00m]
[Loaded]
[HIGH]
[LOW]
[LOW]
000/001
OWN SHIP <4/4>
2013/01/17 22:43:39
Dan
g
erous Tar
g
ets :0IL
[200]
[1000]
[200]
[1400]
[NOT SET]
000/001
Crew Members
Passengers
ShipBoard Personnel
Persons on board
Blue Sign
Additional inland vessel information
AIS targets
This option displays all received AIS information of other vessels
including dynamic and static information. Press the knob to select
an AIS target and then press the knob to go through dynamic and
static information of the selected vessel. There are two pages of ship
details for SOLAS mode and another two pages for inland mode.
AIS TARGET LIST
2013
/
01
/
17 22:44:22
Dangerous Targets :0
[013] - NAME/MMSI ---ET-- BRG( ° ) -- RNG(NM)
RNG
1. 211111161 1s 321 39.54
2. 211111561 1s 314 31.96
3. TEST05 1s 143 19.22
4. TEST10 2s 8 52.66
5. TEST03 1s 293 20.45
6. TEST06 1s 30 30.84
7. TEST08 2s 342 58.81
8. 211111461 3s 274 39.97
9. 211111161 3s 321 39.54
10. TEST02 4s 325 91.62
SHIP DETAIL <1/2>
2013/01/17 22:43:39
Dangerous Targets :0
NAME TEST12
CALL TEST12
MMSI 211000601 [CLASS A]
NAV. Under way using engine
LON 121°54’59”E
LAT 025
°
12’37”N
SOG 26.00Kn
COG 350.8°
ROT N/A
006/023
EPFS Undefined
RNG 10.61NM
BRG 80°
CPA pass
HDG 351.8°
TCPA pass
P.A. Lo
Manoeuvre Ind. not available
RAIM Not in use
AIS targets and details
