Simrad V5035 User Manual

54 |
Operation | V5035 Operator and Installation Manual
SENSOR STATUS
2013/01/17 22:43:39
TX POWER LEVEL: 12.5W
POSITION STATUS EXT. GNSS
UTC STATUS LOST
COG STATUS EXT. COG
SOG STATUS EXT. SOG
HEADING STATUS VALID
ROT STATUS VALID
--DATE TIME--CHANNEL PARAMETER CHANGE--
POSITION QUALITY Posion with RAIM
<= 10 m
Sensor status
Dangerous list
With the setup of closest point of approach (CPA) and time to CPA
(TCPA) (refer to 4.8.3), this submenu provides an efficient way to
monitor vessels with insufficient CPA and TCPA. The dangerous
targets can also be observed on coastal and radar view.
Turn the scroll wheel to navigate the list and press the knob to read
information of the selected vessel. Turn the knob again to go the
second page for more details.
DANGEROUS TARGETS
2013/01/17 22:44:22
[003]-- NAME ------ MMSI -- CPA ----- TCPA -
1. TEST01 210000000 3.84 35.98
TX POWER LEVEL: 12.5W
SHIP DETAIL <1/2>
2013/01/17 22:43:39
TX POWER LEVEL: 12.5W
NAME TEST01
CALL TEST
MMSI 210000000 [CLASS A]
NAV. AIS-SART
LON 121°45’00”E
LAT 025°09’25”N
SOG 3.00Kn
COG 000.0°
ROT 0.0°
001/001
EPFS GPS
RNG 5.43NM
BRG 270°
CPA 3.84 NM
HDG 125.0°
TCPA 54.31 min
P.A Hi
Manoeuvre Ind. not available
RAIM In use
Dangerous list and vessel details
MOB list
With the setup of MOB list, MOB can be easily traced by the person’s
name not just by the MMSI number on the MOB device. This sub-
menu enables adding, removing, or modifying of MOB list entries.
MOB LIST
2013/01/17 17:04:38
TX POWER LEVEL: 12.5W
[000]-- ID ------ NAME --------------------------
MOB LIST
2013/01/17 17:04:39
TX POWER LEVEL: 12.5W
[000]-- ID ------ NAME --------------------------
DELETE
ADD NEW
