Command code 0x08: Circuit Diagnosis and Setting
ADU Item Byte No. Range
Master requests:
Address of slave 1
0～127
Command code 1 0x08
Sub-function code 2
0x0000～0xFFFF
Register data 2
CRC parity 2
Slave responds:
Address of slave 1 Inverter address
Command code 1 0x08
Sub-function code 2
0x0000～0xFFFF
Register data 2
CRC parity 2
Remarks: Command code 0x08 is only for circuit check.
5. Description of Protocol Format
5.1 Address Code
Address of slave inverter. The setting range: 1~247, 0 is broadcast address.
5.2 Command Code
Command Code Function
03H Read parameters and status byte of inverter
06H Write single function code or control parameter of inverter
10H Write several function codes or control parameters of inverter
08H Circuit diagnosis and setting
5.3 Allocation of Register Addresses
Name Address Description
Function
Code
0000H～1F1FH
(Saving
Address)
High byte is the function code group number. F00～
F11, C0, E0, P0, and P1 are corresponding to high bytes:
00H～0BH, 10H, 11H, 12H, and 13H respectively.
Low byte is serial number of function code group. 0~31
corresponding to low bytes 00H~1FH. For example: the
corresponding saving address of F0-07 is 0007H.
2000H～3F1FH
(Temporary
Saving Address)
Frequent modification of EEPROM will reduce its
lifespan. Temporary saving is not required if only
editing the value of function code. To avoid EEPROM
damage, the address of function code+2000H. For
example, the temporary saving address of F0-07 is
2007H.
Control
Command
4000H Refers to Appendix 1
Working
Status
4100H Refers to Appendix 1
